A AR System  administrator can manually integrate  BMC Helix Single Sign-On ( BMC Helix Single Sign-On) with the Jetty server. A manual integration is required when:

• You are using BMC Helix Single Sign-On version 19.05 or earlier.
• The BMC Helix Single Sign-On installation fails.

By default, the  AR System server and Jetty server are installed on the same computer.

Before you begin

• Make sure that the BMC Helix Single Sign-On server is up and running.
• Extract the BMC Helix Single Sign-On installer on a Jetty server.

To manually integrate SSO with Jetty server

1. Stop the AR System server.

2.  In the ar.cfg file located in the ARSystemInstallationDirectory/conf folder, add the following lines:

   Server-Plugin-Alias:
   AREA AREA 127.0.0.1:9999
   External-Authentication-RPC-Socket:390695
   Authentication-Chaining-Mode:2
   Use-Password-File:T
   Crossref-Blank-Password:F
   Allow-Guest-Users: F

3. In the rsso.cfg file, located in the RSSODistr/BMCRemedySSO/Disk1/files/rsso-area-plugin/rsso.cfg folder, perform the following steps:

   1. Define the BMC Helix Single Sign-On server URL. Add the domain name registered with the  BMC Helix Single Sign-On server along with server name.
      SSO-SERVICE-URL: http://RSSOServerName:Port/rsso
      For example, RSSOServerName.domain.com

   2. Copy the modified rsso.cfg file to the ARSystemInstallationDirectory/conf folder.

4. Add the  rsso-agent.properties  file, file and move the rsso-agent.properties file to the ARSystem/Conf folder.

   1. Set the  BMC Helix Single Sign-On properties as shown in the following example.
      Before setting the properties, ensure that the domain name you are using in the URL is registered with the BMC Helix Single Sign-On server.


      agent-id=midtier_agent
      sso-external-url= name>:<RSSOServerPort>/rsso
      sso-service-url= name>:<RSSOServerPort>/rsso
      logout-urls=/api/rsso-logout

5. Perform the following steps to add the  rsso-log.cfg  file and move it to the AR_SERVER_HOME/conf folder:

   1. In the rsso-log.cfg file, update the required information (for example, log directory and log level).
   2. Copy the modified rsso-log.cfg  file  to the AR_SERVER_HOME/conf folder.

6. Perform the following steps to update the pluginsvr_config.xml file located in the AR_SERVER_HOME/pluginsvr folder:

   1. Comment the following plug-ins (if they exist):

      ARSYS.ARF.ATSSOCONFIRMPWD
      ARSYS.AREA.ATRIUMSSO

   2. Add the following plug-ins:

      <plugin>
      <name>ARSYS.AREA.RSSO</name> <classname>com.bmc.rsso.plugin.area.RSSOPlugin</classname> <pathelement
      type="location"><AR_SERVER_HOME>/pluginsvr/rsso-area-plugin-all.jar</pathelement> <pathelement
      type="location"><AR_SERVER_HOME>/pluginsvr/gson-2.3.1.jar</pathelement> <userDefined>
      <configFile><AR_SERVER_HOME>/conf/rsso.cfg</configFile>
      </userDefined>
      </plugin>

      Ensure that the version of the gson-2.3.1.jar file is compatible with the BMC Helix Single Sign-On version installed.

7.  To update the arserverd.config file, located in the ARSystemInstallationDirectory\bin folder, add the following line after  JVM.Option.NN parameters, where NN is next number in the file. For example, if the file contains last number as 22, NN is 23.

   jvm.option.23=-Drsso.log.cfg.file=<AR_SERVER_HOME>/conf/rsso-log.cfg

8. Copy the following JAR files:

   File name	From location	To location
   rsso-area-plugin-all.jar	RSSODistr/BMCRemedySSO/Disk1/files/rsso-area-plugin/rsso-area-plugin-all.jar	AR_SERVER_HOME/pluginsvr
   gson-2.3.1.jar	RSSODistr/BMCRemedySSO/Disk1/files/lib/gson-2.3.1.jar	AR_SERVER_HOME/pluginsvr
   rsso-agent-osgi.jar	RSSODistr/BMCRemedySSO/Disk1/files/rsso-agent/rsso-agent-osgi.jar	AR_SERVER_HOME/deploy

9. Start the AR System server.

BMC Helix Single Sign-On is integrated with the Jetty server.

When the manual integration is complete, on the BMC Helix Single Sign-On server, add a new realm for every tenant. See the following screenshot to learn where to configure a realm.

For more information, see  Adding and configuring realms  in BMC Helix Single Sign-On online documentation.
