Matthew Perez You record and track usage details of fixed and floating licenses using AR System Current License Usage form and AR System Historical License Usage form. By default, BMC Remedy AR System does not record data in these forms. You must turn on the Enable License Tracking option to record the data.
To get a report about license usage, see Generating a license usage report. You can also get information about what type of license a user has by searching the user form.
The following sections provide further details. In addition, this topic provides information specific to tracking server group license usage.
Recording and tracking data in the license usage forms
To record data in the license usage forms
- In the AR System Administration Console, click System > General > Server Information.
- On the Configuration tab, select the required value from the License Tracking field.
- Select Write Licenses or all Licenses from the drop-down, depending on your choice.
- Click Apply.
BMC Remedy AR System immediately starts recording data in the license usage forms. You do not need to restart the AR System server.
To stop recording data in the license usage forms
- In the AR System Administration Console, click System > General > Server Information.
- On the Configuration tab, select Disabled in the License Tracking field.
- Click Apply; then click Save.
Note
All data in the AR System Current License Usage form is lost when:
- The Disabled value is selected in the License Tracking field.
- A standalone server is stopped.
- All servers in a server group are stopped.
AR System Current License Usage form
The AR System Current License Usage form tracks all licenses in use on the server. This form provides information about the servers where the current user is logged in presently. It also shows license details such as floating or fixed license, license acquisition time, application name, and server name where the license is acquired.
Fields in AR System Current License Usage form
Field | Description |
|---|---|
User Name | Name of the user who acquired the license. |
Group ID | ID of the pool that the license belongs to (applies only to floating licenses). |
Application Name | Application that the license applies to. From the 18.05 release, the bundled licenses option is available for this field. |
License Type | Type of license (fixed, floating, read, restricted-read). Note: AR System Current License Usage form tracks only fixed and floating licenses. |
Server Name | Server to which the license is applied. |
Time Acquired | Time that the user acquired the license. Note: When BMC Remedy AR System starts recording data in this form, it creates records for every license in use. Those records include the time that each license was acquired (or consumed), not the time that recording started. For example, if a user acquires license A at 10:15 A.M. and BMC Remedy AR System starts recording data in this form at 10:30 A.M., the Time Acquired for license A is 10:15 A.M |
Type of Record | Type of record used to track license usage:
|
AR System Historical License Usage form
The AR System Historical License Usage form provides historical information about the licenses. This form also records the current license usage.This provides traceability of the current license consumption from this form and the data on this form will be in sync with the License Usage Report. Also, when the user logs out, the records on the AR System Historical License Usage form are updated with the release time of the license. The AR System Historical License Usage form is a single point of reference from where you can determine who is consuming user licenses; whether currently or over a certain period of time in the past. If a user releases a license while the License Tracking option is enabled, an entry is added to the AR System Historical License Usage form. The entry contains information about the usage of that license.
Fields in AR System Historical License Usage form
Field | Description |
|---|---|
User Name | Name of the user who acquired and released the license. |
Group ID | ID of the pool that the license belongs to. Applies only to floating licenses. |
Application Name | Application that the license applies to. From this release, the bundled licenses option is available for this field. |
License Type | Type of license (fixed, floating, read, read-restricted). Note: AR System Historical License Usage form tracks only fixed and floating licenses. |
Time Acquired | Time that the user acquired the license. |
Time Released | Time that the user released the license. If the value of this field is NULL, the user is currently using the license. As soon as the user logs out, this field displays the time stamp of when the current license was released. |
Total Use Time | The total amount of time in seconds that the license was in use. |
AR System Licenses Audit form
From the 18.05 release, you can now view the license usage information, including the details of the licenses that are added, removed, or modified. For this, a new AR System Licenses Audit form is added. To access this form, click Open Audit on the Add or Remove Licenses form.
Tracking server group license usage
When a user first acquires a particular type of license in a server group, the acquisition is recorded in the AR System Current License Usage form as a main record and a subrecord. For example, for a user currently logged into the system, there is one main record, and for every server in the server group the user is logged, there is one subrecord.
If the user acquires another license of the same type on another server in the group without releasing the first license, the second license is recorded as another subrecord of the main record. The same is true of all additional licenses of that type acquired while the main record has at least one subrecord.
When the user logs out of the sessions from a server by releasing one of his licenses, its subrecord for the license is deleted. When the last subrecord is deleted, it indicates that the user has logged out and released all the licenses from the server, the main record is also deleted.
If you stop any server in the server group, all the subrecords for that server are removed when the server is restarted or when another server recognizes that the cleanup is needed for the down server. When the cleanup is performed, the data is not considered valid for use. If all subrecords for a user are removed in this type of cleanup operation, the main record is also removed and in the Historical license usage, the license release time is updated.
