SUBTYPE

TARECID

Level of data in this record

VERSION

TARCDVER

IRUF release identifier

SYSID

TASYSID

Originating system

IMS-LEVL

TAIMSLEV

IMS release level

TRANCODE

TATRAN

Code identifying this message

PSBNAME

TAPSBNAM

Program name

CUSTID1

TACUST

Customer ID (first 9 bytes)

CUSTID2

TACUST

Customer ID (last 9 bytes)

LTERM

TALGTRNM

Logical terminal

REGION

TAREGID

Processing region name

CLASS

TACLASS

Transaction input class

TRANTYPE

TATRANT

Transaction processing type

TRANCAT

TADTRCAT

Transaction category

USER-ID

TAUSERID

Security system user ID

AGN

TAAGN

Application group number

OS-CODE

TAOSCODE

Operating system code

#-TRANS

TATRNSN

Number of transactions run

R-OPTION

TARSPOPT

Response option flag

A-DATE

TAARVDT

Arrival date

A-TIME

TAARVTM

Arrival time

S-DATE

TAXSTART

Processing start date

S-TIME

TAXSTART

Processing start time

E-DATE

TAXENDTM

Processing end date

E-TIME

TAXENDTM

Processing end time

I-Q-TIME

TAINQTM

Time spent in queue

ELAPSED

TAELAPSE

Transaction elapsed time

MSG-CPU

TXMPROCP

Message region CPU time

OPEN-CPU

TXMOPNCP

Open/close CPU time

MSG-DLI

TXMDLICP

Message region DLI CPU time

CTL-DLI

TXCDLICP

Control region DLI CPU time

MSG-BUF

TXMBUFCP

Message region buffer CPU time

CTL-BUF

TXCBUFCP

Control region buffer CPU time

DB2ID

TARESSID

DB2 subsystem ID

DB2-CPU

TAXESSCP

Dependent region CPU time to process DB2 requests

DB2-TRAN

TATRNDB2

Number of transactions that accessed DB2

TRAN-CPU

TAXTCPU

Total CPU time used by the transaction

TTL-CPU

TAXZTCPU

Total dependent region application CPU time including normalized time on ZAAP or ZIIP

NO-Z-CPU

TAXZONCP

Total dependent region application CPU time excluding time on ZAAP or ZIIP

ZAAPELIG

TAXZAOCP

Total dependent region application CPU time eligible for ZAAP that ran on a standard CP

ZIIPELIG

TAXZIOCP

Total dependent region application CPU time eligible for ZIIP that ran on a standard CP

A-STORE

TACRALOC

Allocated storage

U-STORE

TACRUSED

Used storage

A-KSTRGM

TAAKCORE

Allocated KSTORAGE minutes

U-KSTRGM

TAUKCORE

Used KSTORAGE minutes

R-MSWCNT ¹

TARSWCNT

Message switch count

R-MSNTCT ¹

TARSENCT

Message sent count

R-MDQCNT ¹

TARDEQCT

Message dequeue count

R-MSWLEVL ¹

TARMSGLV

Message switching level

R-ORIGDT ¹

TAXORGSW

Original arrival date

R-ORIGTM ¹

TAXORGSW

Original arrival time

R-ADATE ¹

TARARVDT

Message switch arrival date

R-ATIME ¹

TARARVTM

Message switch arrival time

R-IDATE ¹

TAXISRDT

Output message insert date

R-ITIME ¹

TAXISRDT

Output message insert time

R-SDATE ¹

TAXSNTDT

Output message sent date

R-STIME ¹

TAXSNTDT

Output message sent time

R-DDATE ¹

TAXDEQDT

Output message dequeue date

R-D-TIME ¹

TAXDEQCT

Output message dequeue time

R-LINE ¹

TALINE

Input line number

R-PTERM ¹

TAPTERM

Input physical terminal

R-INPUTQ ¹

TAXINQTM

Alternate input queue time

R-OUTPTQ ¹

TAXOUTQ

Alternate output queue time

R-DE-Q ¹

TAXDEQ

Alternate dequeue time

R-RESPON ¹

TAXRSP

Alternate response time

R-OMSCDT

TAXORGAR

Original MSC transaction date

R-OMSCTM

TAXORGAR

Original MSC transaction time

R-DSMSCD

TAXMSCAR

MSC destination transaction arrival date

R-DSTMSCT

TAXMSCAR

MSC destination transaction arrival time

R-IQ-MSW

TAXINQ

Transaction input queue time

R-OARVLD

TAXARVDT

Transaction arrival date

R-OARVLT

TAXARVDT

Transaction arrival time

$-ASTORE

TACRACHG

Charge for allocated KSTORAGE

$-USTORE

TACRUCHG

Charge for used KSTORAGE

$-MSGCPU

TAMSPCHG

Charge for message region CPU time

$-MIN

TACDCHG

Minimum transaction charge

$-MSGDLI

TAMSDCHG

Charge for message region DL/I CPU time

$-CTLDLI

TAMSCCHG

Charge for control region DL/I CPU time

$-RESRCE

TARESCHG

Total resource charges

$-UNIT

TAUNTCHG

Transaction unit charge

$-PRORAT

TAPROCHG

Total prorated charges

$-BILABL

TABILCHG

Total charge

$-VAR

TAVARCHG

Charge variance

$DB2CPU

TAXESSCP

Charge for dependent region DB2 CPU time

SAP FLG

TASAPX

SAP exit-invoked indicator (Y or N)

U-AREA1

TAUSER

User area (first 10 bytes)

U-AREA2

TAUSER

User area (last 10 Bytes)

#-SEGS

TANOSEGS

Number of segments

SMQGRPNM

TASMQGPN

Shared message queues group name

ABENDCOD

TAABNCOD

Transaction abend code

SPRC

TASPRC

Fast Path sync point return code

BGQCT

TABGQCT

Fast Path balancing group queue count

MSG-OPN

TXMOPNCP

Dependent region open/close CPU time

RTCODE

TARC

Fast Path routing code

NBA

TANBA

Fast Path normal buffer allocation

OBA

TAOBA

Fast Path overflow buffer allocation

BUSED

TABUSED

Fast Path buffers used

NCIC

TANCIC

Number of Fast Path CI contentions

NWFB

TANWFB

Number of waits for Fast Path buffers

WFOBL

TAFLAG

Wait for Fast Path overflow buffer latch

MISC-IWT

TARW1OTH

Miscellaneous IWAIT time

SYNC-IWT

TARW2OTH

Sync miscellaneous IWAIT time

SYNLATCH

TARW2LCH

Sync latch IWAIT time

SYNCVSAM

TARW2IOV

Sync VSAM I/O IWAIT time

SYNCOSAM

TARW2IOO

Sync OSAM I/O IWAIT time

DLITMMSC

TARW3OTH

DLI/TM miscellaneous IWAIT time

DLITMLAT

TARW3LCH

DLI/TM latch IWAIT time

MISC-OC

TARW4OTH

Open/Close miscellaneous IWAIT time

DBRC-OC

TARW4DBR

Open/Close DBRC IWAIT time

I/O-OC

TARW4IO

Open/Close I/O IWAIT time

DLIDB-M

TARW5OTH

DLI/DB miscellaneous IWAIT time

DLIDB-LAT

TARW5LCH

DLI/DB latch IWAIT time

DLIDBLOC

TARW5LCK

DLI/DB lock IWAIT time

DLIDBVSM

TARW5IOV

DLI/DB VSAM IWAIT time

DLIDBOSM

TARW5IOO

DLI/DB OSAM IWAIT time

DLIDBDEDB

TARW5IOD

DLI/DB DEDB IWAIT time

APPL-ELP

TAREAPPL

Application elapsed time

DLIT-ELP

TAREDLTM

DLI/TM elapsed time

DLID-ELP

TAREDLDB

DLI/DB elapsed time

DB2-ELAP

TAREDB2

DB2 elapsed time

MQS-ELP

TAREMQS

MQS elapsed time

ESS-ELP

TAREOESS

ESS elapsed time

OPCL-ELP

TAREOPCL

Open/Close elapsed time

SYNC-ELP

TARESYNC

Sync elapsed time

1ST-DLI

TARE1STD

Schedule to first DL/I call elapsed time

DLI-LAST

TARELDLI

DL/I last call elapsed time

FLSE-ELP

TARFALST

False schedule elapse time

CPU-AFTER

TARXCPU

CPU time after transaction stop is set

CNT/PTS

TARXCKPC

Count of checkpoints and syncpoints

MAX-LOCK

TARXCKPM

Maximum number of locks held (highwater mark)

TOT-LOCK

TARXCKPT

Total number of locks held for all checkpoints

CON-DATE

TAROTCON

IMS Connect start date

CON-TIME

TAROTCON

IMS Connect start time

CON-NAME

TAROTSTC

IMS Connect jobname or started task name

PORT-ID

TAROTPRT

IMS Connect port ID

CLNTTYPE

TAROTMCL

OTMA client type

CON-IP

TAROTIP

IMS Connect client IP address

CLNT ID

TAROTCLN

IMS Connect client ID

SEC-USRID

TAROTUSR

OTMA security user ID

OTMACOR

TAROTCOR

OTMA correlator

CLNTPTID

TAROTCLP

IMS Connect client port ID

TMEMNAME

TAROTMAM

OTMA Tmember name

FALSESCHD

TARFALSC

Number of false schedules

RSE-NAME

TARRSENM

RSE name

MAP-NAME

TAROTMAP

OTMA map name

CICSAPPL

TARCAPPL

CICS application ID

SEGTYPE ¹

TARPCBA

I/O PCB segment

LTERM ¹

TATERMNM

Originating LTERM

LINENBR ¹

TAPCLN

PCB line number

CON-TIME ¹

TAPCONTM

Connect time

#-MGU ¹

TAPCIOGU

Number of message get uniques

#-MGN ¹

TAPCIOGN

Number of message get nexts

#-MISRT ¹

TAPCIOIN

Number of message inserts

#-MPURGE ¹

TAPCIOPU

Number of message purges

#-MOTHR ¹

TAPCIOOT

Number of other message calls

CNT-IN ¹

TAIMSGCT

Number of bytes input

IN-SPA ¹

TAISPACT

Number of bytes input to SPA

IN-OTHR ¹

TAIOTHCT

Number of other bytes input

CNT-OUT ¹

TAOMSGCT

Number of bytes output

OUT-SPA ¹

TAOSPACT

Number of bytes output from SPA

OUT-ATER ¹

TAATERCT

Number of bytes output from alternate area

OUT-ATRN ¹

TAATRNCT

Number of bytes output from alternate message

OUT-OTHR ¹

TAOOTHCT

Number of other bytes output

$-CONECT ¹

TAPCCHCC

Charge for connect time

$-MGU ¹

TAPCCHGU

Charge for message get uniques

$-MGN ¹

TAPCCHGN

Charge for message get nexts

$-MISRT ¹

TAPCCHIN

Charge for message inserts

$-MPURGE ¹

TAPCCHPU

Charge for message purges

$-MOTHR ¹

TAPICHOT

Charge for other characters

$-INPUT ¹

TAPCCHIC

Charge for input characters

$-IN-SPA ¹

TAPCCHIS

Charge for input space characters

$-IN-OTH ¹

TAPCHIOT

Charge for other input characters

$-OUTPUT ¹

TAPCCHOC

Charge for output characters

$-OUTSPA ¹

TAPCCHOS

Charge for output space characters

$-OUTATER ¹

TAPCHTMS

Charge for alternate characters

$-O-ATRN ¹

TAPCHTNC

Charge for alternate message queue characters

$-OTHER ¹

TAPOCHOT

Charge for other characters

SEGTYPE ²

TASEGTPD

DBD segment

DB/DD-NM ²

TAD2DNM

D2D or DD name

Note

The IRUF trailer information is collected either at the data2ase or data set level based on the setting of the DBTNAME parameter in the IMFECPxx parameter mem2er. That is, DBTNAME=DB or DBTNAME=DD.

The D2/DD-NM field can be a DBD name or a DD name, based on the setting that was in place when the data was collected.

D2DORG ²

TADORG

DBD organization

DMB-SIZE ²

TADMBPLS

DMB pool requirements

#-GU ²

TADBIOGU

Number of get uniques

#-GN ²

TADBIOGN

Number of get nexts

#-ISRT ²

TADBIOIN

Number of inserts

#-DELETE ²

TADBIODL

Number of deletes

#-REPL ²

TADBIORP

Number of replaces

#-OTHER ²

TADBIOOT

Number of other calls

#-ISAMR ²

TADBIOIR

Number of ISAM key reads

#-ISAMW ²

TADBIOIW

Number of ISAM key writes

#-OSAMR ²

TADBIOOR

Number of OSAM nonkey reads

#-OSAMW ²

TADBIOOW

Number of OSAM nonkey writes

#-REFS ²

TADBIOCT

Number of transactions that referenced this database

#-DB2DLI ²

TADB2DLI

Number of DL/I calls made if a transaction also accesses DB2

#-NO-I ²

TADBIONI

Number of I/O inputs

#-NO-O ²

TADBIONO

Number of I/O outputs

DB-VERSN ²

TADBVERS

IMS database version number

$-GU ²

TADBCHGU

Charge for get uniques

$-GN ²

TADBCHGN

Charge for get nexts

$-ISRT ²

TADBCHIN

Charge for inserts

$-DELETE ²

TADBCHDL

Charge for deletes

$-REPL ²

TADBCHRP

Charge for replaces

$-OTHER ²

TADBCHOT

Charge for other DLI calls

$-ISAMR ²

TADBCHIR

Charge for ISAM key reads

$-ISAMW ²

TADBCHIW

Charge for ISAM key writes

$-OSAMR ²

TADBCHOR

Charge for OSAM nonkey reads

$-OSAMW ²

TADBCHOW

Charge for OSAM nonkey writes

$-NO-I ²

TADBCHNI

Charge for I/O inputs

$-NO-O ²

TADBCHNO

Charge for I/O outputs

PLANNAME ³

TAD2PLAN

DB2 plan name for transaction

#-SEL/F ³

TAD2SEL

Number of SQL select and fetch calls

#-OPENS ³

TAD2OPEN

Number of SQL open calls

#-ISRT ³

TAD2ISRT

Number of SQL insert calls

#-DELETE ³

TAD2DLET

Number of SQL delete calls

#-UPD ³

TAD2UPD

Number of SQL update calls

#-DDL ³

TAD2DDL

Number of SQL Data Definition Language calls

#-DYN ³

TAD2DYN

Number of SQL dynamic calls

#-CTRL ³

TAD2CTRL

Number of SQL control-type calls

#-OTHER ³

TAD2OTHR

Number of other SQL calls

#-REFS ³

TAD2REFS

Number of transactions that referenced DB2

$-READ ³

TAD2CHGR

Charge for number of read-type calls

$-UPDATE ³

TAD2CHGU

Charge for number of update-type calls

$-DDL ³

TAD2CHGD

Charge for number of Data Definition Language calls

$-DYN ³

TAD2CHGY

Charge for number of dynamic SQL calls

$-CTRL ³

TAD2CHGC

Charge for number of control-type calls

$-OTHER ³

TAD2CHGO

Charge for number of other DB2 calls

SEGTYPE ⁴

TAMSEGTY

MQ segment

The value is M.

MQ-SSID ⁴

TAMSSID

ID of the MQ subsytem

#-GET ⁴

TAMQGET

Number of GET calls

#-PUT ⁴

TAMQPUT

Number of PUT calls

#-PUT1 ⁴

TAMQPUT1

Number of PUT1 calls

#-SET ⁴

TAMQSET

Number of SET calls

#-OPEN ⁴

TAMQOPEN

Number of OPEN calls

#-CLOSE ⁴

TAMQCLOS

Number of CLOSE calls

#-BACK ⁴

TAMQBACK

Number of BACK calls

#-CMT ⁴

TAMQCMT

Number of CMT calls

#-CONN ⁴

TAMQCONN

Number of CONN calls

#-DISC ⁴

TAMQDISC

Number of DISC calls

#-INQ ⁴

TAMQINQ

Number of INQ calls

#-UNKN ⁴

TAMQUNKN

Number of calls with an unknown type

$-GET ⁴

TAMQCHGG

Amount charged for GET calls

$-PUT ⁴

TAMQCHGP

Amount charged for PUT calls

$-PUT1 ⁴

TAMQCHG1

Amount charged for PUT1 calls

$-SET ⁴

TAMQCHGS

Amount charged for SET calls

$-OPEN ⁴

TAMQCHGO

Amount charged for OPEN calls

$-CLOSE ⁴

TAMQCHGC

Amount charged for CLOSE calls

$-BACK ⁴

TAMQCHGB

Amount charged for BACK calls

$-CMT ⁴

TAMQCHGT

Amount charged for CMT calls

$-CONN ⁴

TAMQCHGN

Amount charged for CONN calls

$-DISC ⁴

TAMQCHGD

Amount charged for DISC calls

$-INQ ⁴

TAMQCHGI

Amount charged for INQ calls

$-UNKN ⁴

TAMQCHGU

Amount charged for calls of an unknown type

SEGTYPE ⁵

TASEGTPR

Response segment

R-TRNCAT ⁵

TARESCAT

Transaction category

R-RESPTM ⁵

TARSPTM0

Response time work area

R-RESPCNT ⁵

TARSPCT0

Response count work area

R-RSPTM1 ⁵

TARSPTM1

Response threshold 1

R-RSPCT1 ⁵

TARSPCT1

Transaction count 1

R-RSPTM2 ⁵

TARSPTM2

Response threshold 2

R-RSPCT2 ⁵

TARSPCT2

Transaction count 2

R-RSPTM3 ⁵

TARSPTM3

Response threshold 3

R-RSPCT3 ⁵

TARSPCT3

Transaction count 3

R-RSPTM4 ⁵

TARSPTM4

Response threshold 4

R-RSPCT4 ⁵

TARSPCT4

Transaction count 4

R-RSPTM5 ⁵

TARSPTM5

Response threshold 5

R-RSPCT5 ⁵

TARSPCT5

Transaction count 5

R-RSPTM6 ⁵

TARSPTM6

Response threshold 6

R-RSPCT6 ⁵

TARSPCT6

Transaction count 6

R-RSPTM7 ⁵

TARSPTM7

Response threshold 7

R-RSPCT7 ⁵

TARSPCT7

Transaction count 7

R-RSPTM8 ⁵

TARSPTM8

Response threshold 8

R-RSPCT8 ⁵

TARSPCT8

Transaction count 8

R-RSPTM9 ⁵

TARSPTM9

Response threshold 9

R-RSPCT9 ⁵

TARSPCT9

Transaction count 9

R-RSPT10 ⁵

TARSPTMA

Response threshold 10

R-RSPC10 ⁵

TARSPCTA

Transaction count 10

R-RSPT11 ⁵

TARSPTMB

Response threshold 11

R-RSPC11 ⁵

TARSPCTB

Transaction count 11

R-RSPT12 ⁵

TARSPTMC

Response threshold 12

R-RSPC12 ⁵

TARSPCTC

Transaction count 12
