The rich text format (RTF) editor is a simple text editor that you use to format the text in fields. It provides commonly used functions, such as formatting text, creating tables, inserting links, and creating and linking bookmarks. The RTF editor reduces the efforts of formatting the text by providing a What-You-See-Is-What-You-Get (WYSIWYG) interface. You can use the RTF editor in fields that have the RTF icon next to them.

For information on RTF editors for Progressive Web Applications (PWA), see Adding RTF fields in Progressive Web Applications.

Features of the RTF editor

The RTF editor has the following features:

Supports all use cases for rich-text fields in BMC Helix ITSM: Knowledge Management applications.
- When the article content uses standard HTML markup, this RTF editor renders the article without any loss of formatting.
- Helps you edit the existing articles.
Supports rich-text field editing capabilities.
Maintains formatting when you copy content from Microsoft Word, Microsoft Outlook, or HTML and paste it into an RTF-enabled field.
To maintain the look and feel of forms, global styling of the content pasted from other sources such as Microsoft Word, Microsoft Outlook, or HTML is removed. However, the inline styling continues to work.

Functions available in the RTF editor

Function	Description	Type of editor
	Sets paragraph formatting style such as headings and address.	Pop-up editor
	Selects the font type and point size from the list.	Inline editor and Pop-up editor
	Selects the text color and text background from the list.	Inline editor and Pop-up editor
	Makes the selected text bold, italicized, underlined, or strikethrough.	Inline editor and Pop-up editor
	Makes the selected text subscript or superscript, and clears formatting.	Pop-up editor
	Finds and replaces text.	Pop-up editor
	Increases or decreases the selected text's distance from the left margin.	Pop-up editor
	Sets the paragraph so that it aligns evenly on the left, center, or right; or justifies the text.	Pop-up editor
	Creates an ordered or unordered list.	Pop-up editor
	Inserts a link to any URL, to a bookmark, or to an email. The unlink icon removes the created link. For more information, see Adding and removing links below.	Pop-up editor
	Creates a bookmark in a document that is referred through a URL. For more information, see To create a bookmark below.	Pop-up editor
	Inserts an image into the RTF field. For more information, see Adding an image below.	Pop-up editor
	Inserts a table into the RTF field. For more information, see Adding a table below .	Inline editor and Pop-up editor
	Adds an expandable section to provide additional information.	Pop-up editor
	Adds special formatting features, such as a horizontal rule, smiley, and special characters.	Pop-up editor
	(Microsoft Internet Explorer 11 only) Removes, copies, and pastes selected text to and from the clipboard.	Pop-up editor
	Removes the last 30 changes made in the RTF editor or reverses the undo action.	Pop-up editor

Adding and removing links

You can perform following actions with the Link icon.

To create a bookmark

Select the text in the pop-up editor for which you want to create a bookmark.
Click the bookmark icon.
In the Bookmark Properties dialog, provide a name for the bookmark.
Click OK.

The following screenshot illustrates the bookmarked text displayed in blue color with a blue dashed border.

To edit the bookmark name or remove the bookmark, right-click and select the appropriate option.

To add an image to a character field

Click the Image icon .
Specify the URL to access the image.
You can also define alternative text for the image.
(Optional) Set the options for height, width, border, Hspace, Vspace, and alignment.
Click OK .

You can preview the image in the Preview pane before adding it to the field.

Adding a table

You can use the Table icon to insert a table in an RTF field or to modify the properties of a selected table. The Table Properties dialog box allows you to design a table with advanced options.

In the RTF editor, when you right-click the table, you can perform following operations:

Paste contents in the table.
Insert cells, rows, and columns (before or after).
Merge cells (right or down).
Split cells (horizontal and vertical).
Set cells properties.
Set table properties.
Delete cells, rows, and columns.
Edit and remove division.
Delete the table.

Shortcut keys in the RTF editor

Shortcut keys provide a quick and easy method of navigating and executing operations. The following tables list the shortcut keys available in the RTF editor provided by Mid Tier .

General RTF shortcut keys

Shortcut key	Description
Esc	Closes an RTF dialog box, drop-down list, or context menu. Equivalent to the Cancel button in a dialog box.
ENTER	Selects a RTF function from the toolbar, drop-down list, or context menu. Equivalent to the OK button in a dialog box.
SHIFT+F10, Menu Application	Opens the element's context menu.
HOME	Moves the cursor to the beginning of the line.
CTRL+HOME	Moves the cursor to the beginning of the document.
END	Moves the cursor to the end of the line.
CTRL+END	Moves the cursor to the end of the document.
PgDn	Scrolls down the document.
PgUp	Scrolls up the document.
CTRL+Z	Performs an undo operation.
CTRL+Y or SHIFT+CTRL+Z	Performs a redo operation.
CTRL+X or SHIFT+DEL	Cuts a text fragment.
CTRL+C	Copies a text fragment.
CTRL+V or SHIFT+INSERT	Pastes a text fragment from the clipboard.

RTF shortcut keys for writing

Shortcut Key	Description
ENTER (RETURN)	Ends a paragraph and starts a new one.
SHIFT+ENTER	Adds a line break.
SHIFT+CTRL+3	Enables entering content (by adding a new paragraph) before a problematic element, such as an image, table, or `<div>` element.
SHIFT+CTRL+4	Enables entering content (by adding a new paragraph) after a problematic element, such as an image, table or, `<div>` element.
BACKSPACE or DEL	Deletes a character.
CTRL+BACKSPACE or CTRL+DEL	Deletes a word.

RTF shortcut keys for text selection and styling

Shortcut key	Description
CTRL+A	Selects all document content.
SHIFT+ARROW	Selects a text fragment by letters.
CTRL+SHIFT+ARROW	Selects a text fragment by words.
SHIFT+HOME	Selects a text fragment from the cursor to the beginning of the line.
SHIFT+END	Selects a text fragment from the cursor to the end of the line.
CTRL+SHIFT+HOME	Selects a text fragment from the cursor to the beginning of the document.
CTRL+SHIFT+END	Selects a text fragment from the cursor to the end of the document.
SHIFT+PgDn	Selects a text fragment starting from the cursor and going down.
SHIFT+PgUp	Selects a text fragment starting from the cursor and going up.
CTRL+B	Applies bold formatting to a text fragment.
CTRL+I	Applies italics formatting to a text fragment.
CTRL+U	Applies underline formatting to a text fragment.

RTF shortcut keys for copy formatting

Shortcut key	Description
CTRL+SHIFT+C	Copies the inline formatting from a text fragment and enables the sticky mode.
CTRL+SHIFT+V	Applies the previously copied inline formatting to a text fragment.
ESC	Disables the sticky mode.
CTRL + Right click	Enables the spell check option in the browser.

RTF shortcut keys for Rich text

Shortcut key	Description
CTRL+L	Opens the Link dialog box.
TAB	Indents a list.
SHIFT+TAB	Outdents a list.

RTF shortcut keys for keyboard support

Shortcut key	Description
ALT+F10	Opens the editor toolbar. Use the TAB and SHIFT+TAB to move between toolbar groups. Use ARROW keys to move between the buttons within a toolbar group.

Troubleshooting

In some cases, the resize handle arrow on the bottom of the RTF editor dialog box disappears. Solution: Close and re-open the RTF editor. The resize handle appears.
