UI Name

Relationship

Description

Activity Records

ActedUpon:
Activity:
ActivityRecord:
ActivityRecord

Record of model activity associated with this Virtual Machine

Administrative Collections

Member:
Collection:
Collection:
AdminCollection

Administrative Collections this Virtual Machine is a member of

Collections

Member:
Collection:
Collection:
Collection

Collections this Virtual Machine is a member of

Deployments

Member:
Collection:
Collection:
Deployment

Deployments this Virtual Machine is a member of

Subnets

Member:
Collection:
Collection:
Subnet

Subnets this Virtual Machine is a member of

Namespace

Member:
Collection:
Collection:
Namespace

Namespace this Virtual Machine is in

Disk Drives

Container:
Containment:
ContainedDrive:
DiskDrive

Disk Drives contained in this Virtual Machine

Tape Drives

Container:
Containment:
ContainedDrive:
TapeDrive

Tape Drives contained in this Virtual Machine

Excluded from Model Definitions

ExcludedItem:
DefinitionContainment:
Definition:
ModelDefinition

Model Definitions this Virtual Machine has been excluded from

Included in Model Definitions

IncludedItem:
DefinitionContainment:
Definition:
ModelDefinition

Model Definitions this Virtual Machine is included in

Clusters Depending Upon This

DependedUpon:
Dependency:
Dependant:
Cluster

Clusters that depend on this Virtual Machine

Databases Depending Upon This

DependedUpon:
Dependency:
Dependant:
Database

Databases that depend on this Virtual Machine

Details Depending Upon This

DependedUpon:
Dependency:
Dependant:
Detail

Details that depend on this Virtual Machine

Software Clusters Depending Upon This

DependedUpon:
Dependency:
Dependant:
SoftwareCluster

Software Clusters that depend on this Virtual Machine

Software Components Depending Upon This

DependedUpon:
Dependency:
Dependant:
SoftwareComponent

Software Components that depend on this Virtual Machine

Software Containers Depending Upon This

DependedUpon:
Dependency:
Dependant:
SoftwareContainer

Software Containers that depend on this Virtual Machine

Software Instances Depending Upon This

DependedUpon:
Dependency:
Dependant:
SoftwareInstance

Software Instances that depend on this Virtual Machine

Software Pods Depending Upon This

DependedUpon:
Dependency:
Dependant:
SoftwarePod

Software Pods that depend on this Virtual Machine

Clusters This Depends On

Dependant:
Dependency:
DependedUpon:
Cluster

Clusters that this Virtual Machine depends on

Databases This Depends On

Dependant:
Dependency:
DependedUpon:
Database

Databases that this Virtual Machine depends on

Database Details This Depends On

Dependant:
Dependency:
DependedUpon:
DatabaseDetail

Database Details that this Virtual Machine depends on

Details This Depends On

Dependant:
Dependency:
DependedUpon:
Detail

Details that this Virtual Machine depends on

Files This Depends On

Dependant:
Dependency:
DependedUpon:
File

Files that this Virtual Machine depends on

Runtime Environments This Depends On

Dependant:
Dependency:
DependedUpon:
RuntimeEnvironment

Runtime Environments that this Virtual Machine depends on

Software Clusters This Depends On

Dependant:
Dependency:
DependedUpon:
SoftwareCluster

Software Clusters that this Virtual Machine depends on

Software Components This Depends On

Dependant:
Dependency:
DependedUpon:
SoftwareComponent

Software Components that this Virtual Machine depends on

Software Instances This Depends On

Dependant:
Dependency:
DependedUpon:
SoftwareInstance

Software Instances that this Virtual Machine depends on

Software Pods This Depends On

Dependant:
Dependency:
DependedUpon:
SoftwarePod

Software Pods that this Virtual Machine depends on

Virtual Machines This Depends On

Dependant:
Dependency:
DependedUpon:
VirtualMachine

Virtual Machines that this Virtual Machine depends on

Virtual Machines Depending Upon This

DependedUpon:
Dependency:
Dependant:
VirtualMachine

Virtual Machines that depend on this Virtual Machine

Details

ElementWithDetail:
Detail:
Detail:
Detail

Details belonging to this Virtual Machine

Hardware Details

ElementWithDetail:
Detail:
Detail:
HardwareDetail

Hardware Details belonging to this Virtual Machine

Network Interfaces

DeviceWithInterface:
DeviceInterface:
InterfaceOfVirtualMachine:
NetworkInterface

Network Interfaces of this Virtual Machine

Discovery Conditions

ElementWithCondition:
DiscoveryCondition:
DiscoveryCondition:
DiscoveryCondition

Discovery Conditions affecting this Virtual Machine

Cluster

ContainedHost:
HostContainment:
HostContainer:
Cluster

Cluster of which this is a member

Contained Host

HostContainer:
HostContainment:
ContainedHost:
Host

Hosts provided by this Virtual Machine

Contained MF Part

HostContainer:
HostContainment:
ContainedHost:
MFPart

MF Parts provided by this Virtual Machine

Contained Network Device

HostContainer:
HostContainment:
ContainedHost:
NetworkDevice

Network Devices provided by this Virtual Machine

Contained SNMP Managed Device

HostContainer:
HostContainment:
ContainedHost:
SNMPManagedDevice

SNMP Managed Devices provided by this Virtual Machine

Contained Storage Device

HostContainer:
HostContainment:
ContainedHost:
StorageDevice

Storage Devices provided by this Virtual Machine

Contained Storage System

HostContainer:
HostContainment:
ContainedHost:
StorageSystem

Storage Systems provided by this Virtual Machine

Cloud Service

RunningSoftware:
HostedSoftware:
Host:
CloudService

Cloud Service on which this Virtual Machine is running

Cluster

RunningSoftware:
HostedSoftware:
Host:
Cluster

Cluster on which this Virtual Machine is running

Host

RunningSoftware:
HostedSoftware:
Host:
Host

Host on which this Virtual Machine is running

MF Part

RunningSoftware:
HostedSoftware:
Host:
MFPart

MF Part on which this Virtual Machine is running

Network Device

RunningSoftware:
HostedSoftware:
Host:
NetworkDevice

Network Device on which this Virtual Machine is running

Associated Business Applications

InferredElement:
Inference:
Associate:
BusinessApplicationInstance

Business Applications associated in some way with this Virtual Machine

Associated Discovered API Results

InferredElement:
Inference:
Associate:
DiscoveredAPIResult

Discovered API Results associated in some way with this Virtual Machine

Associated Discovered Command Results

InferredElement:
Inference:
Associate:
DiscoveredCommandResult

Discovered Command Results associated in some way with this Virtual Machine

Associated Discovered DNS Details

InferredElement:
Inference:
Associate:
DiscoveredDNSDetail

Discovered DNS Details associated in some way with this Virtual Machine

Associated Discovered Directory Entries

InferredElement:
Inference:
Associate:
DiscoveredDirectoryEntry

Discovered Directory Entries associated in some way with this Virtual Machine

Associated Discovered Files

InferredElement:
Inference:
Associate:
DiscoveredFile

Discovered Files associated in some way with this Virtual Machine

Associated Listening Ports

InferredElement:
Inference:
Associate:
DiscoveredListeningPort

Listening Ports associated in some way with this Virtual Machine

Associated Network Connections

InferredElement:
Inference:
Associate:
DiscoveredNetworkConnection

Network Connections associated in some way with this Virtual Machine

Associated Discovered Packages

InferredElement:
Inference:
Associate:
DiscoveredPackages

Discovered Packages associated in some way with this Virtual Machine

Associated Discovered Processes

InferredElement:
Inference:
Associate:
DiscoveredProcess

Discovered Processes associated in some way with this Virtual Machine

Associated Discovered Registry Entries

InferredElement:
Inference:
Associate:
DiscoveredRegistryEntry

Discovered Registry Entries associated in some way with this Virtual Machine

Associated Discovered Registry Values

InferredElement:
Inference:
Associate:
DiscoveredRegistryValue

Discovered Registry Values associated in some way with this Virtual Machine

Associated Discovered SNMP Values

InferredElement:
Inference:
Associate:
DiscoveredSNMP

Discovered SNMP Values associated in some way with this Virtual Machine

Associated Discovered SNMP Table Rows

InferredElement:
Inference:
Associate:
DiscoveredSNMPRow

Discovered SNMP Table Rows associated in some way with this Virtual Machine

Associated Discovered Services

InferredElement:
Inference:
Associate:
DiscoveredService

Discovered Services associated in some way with this Virtual Machine

Associated Discovered Software

InferredElement:
Inference:
Associate:
DiscoveredSoftware

Discovered Software associated in some way with this Virtual Machine

Associated Discovered Virtual Machines

InferredElement:
Inference:
Associate:
DiscoveredVirtualMachine

Discovered Virtual Machines associated in some way with this Virtual Machine

Associated Discovered WBEM Associators Results

InferredElement:
Inference:
Associate:
DiscoveredWBEMAssociatorsResult

Discovered WBEM Associators Results associated in some way with this Virtual Machine

Associated Discovered WBEM Instances

InferredElement:
Inference:
Associate:
DiscoveredWBEMInstance

Discovered WBEM Instances associated in some way with this Virtual Machine

Associated Discovered WBEM Query Results

InferredElement:
Inference:
Associate:
DiscoveredWBEMQueryResult

Discovered WBEM Query Results associated in some way with this Virtual Machine

Associated Discovered WMI Query Results

InferredElement:
Inference:
Associate:
DiscoveredWMI

Discovered WMI Query Results associated in some way with this Virtual Machine

Associated Hardware Details

InferredElement:
Inference:
Associate:
HardwareDetail

Hardware Details associated in some way with this Virtual Machine

Associated Hosts

InferredElement:
Inference:
Associate:
Host

Hosts associated in some way with this Virtual Machine

Associated Packages

InferredElement:
Inference:
Associate:
Package

Packages associated in some way with this Virtual Machine

Associated Software Components

InferredElement:
Inference:
Associate:
SoftwareComponent

Software Components associated in some way with this Virtual Machine

Associated Software Containers

InferredElement:
Inference:
Associate:
SoftwareContainer

Software Containers associated in some way with this Virtual Machine

Associated Software Instances

InferredElement:
Inference:
Associate:
SoftwareInstance

Software Instances associated in some way with this Virtual Machine

Contributor Business Applications

InferredElement:
Inference:
Contributor:
BusinessApplicationInstance

Business Applications contributing to this Virtual Machine's attributes

Contributor Business Services

InferredElement:
Inference:
Contributor:
BusinessService

Business Services contributing to this Virtual Machine's attributes

Contributor Technical Services

InferredElement:
Inference:
Contributor:
TechnicalService

Technical Services contributing to this Virtual Machine's attributes

Contributor Discovered API Results

InferredElement:
Inference:
Contributor:
DiscoveredAPIResult

Discovered API Results contributing to this Virtual Machine's attributes

Contributor Discovered Command Results

InferredElement:
Inference:
Contributor:
DiscoveredCommandResult

Discovered Command Results contributing to this Virtual Machine's attributes

Contributor Discovered DNS Details

InferredElement:
Inference:
Contributor:
DiscoveredDNSDetail

Discovered DNS Details contributing to this Virtual Machine's attributes

Contributor Discovered Directory Entries

InferredElement:
Inference:
Contributor:
DiscoveredDirectoryEntry

Discovered Directory Entries contributing to this Virtual Machine's attributes

Contributor Discovered FQDNs

InferredElement:
Inference:
Contributor:
DiscoveredFQDN

Discovered FQDNs contributing to this Virtual Machine's attributes

Contributor Discovered Files

InferredElement:
Inference:
Contributor:
DiscoveredFile

Discovered Files contributing to this Virtual Machine's attributes

Contributor Listening Ports

InferredElement:
Inference:
Contributor:
DiscoveredListeningPort

Listening Ports contributing to this Virtual Machine's attributes

Contributor Network Connections

InferredElement:
Inference:
Contributor:
DiscoveredNetworkConnection

Network Connections contributing to this Virtual Machine's attributes

Contributor Discovered Packages

InferredElement:
Inference:
Contributor:
DiscoveredPackages

Discovered Packages contributing to this Virtual Machine's attributes

Contributor Discovered Patches

InferredElement:
Inference:
Contributor:
DiscoveredPatches

Discovered Patches contributing to this Virtual Machine's attributes

Contributor Discovered Processes

InferredElement:
Inference:
Contributor:
DiscoveredProcess

Discovered Processes contributing to this Virtual Machine's attributes

Contributor Discovered Registry Entries

InferredElement:
Inference:
Contributor:
DiscoveredRegistryEntry

Discovered Registry Entries contributing to this Virtual Machine's attributes

Contributor Discovered Registry Values

InferredElement:
Inference:
Contributor:
DiscoveredRegistryValue

Discovered Registry Values contributing to this Virtual Machine's attributes

Contributor Discovered SNMP Values

InferredElement:
Inference:
Contributor:
DiscoveredSNMP

Discovered SNMP Values contributing to this Virtual Machine's attributes

Contributor Discovered SNMP Table Rows

InferredElement:
Inference:
Contributor:
DiscoveredSNMPRow

Discovered SNMP Table Rows contributing to this Virtual Machine's attributes

Contributor Discovered Services

InferredElement:
Inference:
Contributor:
DiscoveredService

Discovered Services contributing to this Virtual Machine's attributes

Contributor Discovered Software

InferredElement:
Inference:
Contributor:
DiscoveredSoftware

Discovered Software contributing to this Virtual Machine's attributes

Contributor Discovered Virtual Machines

InferredElement:
Inference:
Contributor:
DiscoveredVirtualMachine

Discovered Virtual Machines contributing to this Virtual Machine's attributes

Contributor Discovered WBEM Associators Results

InferredElement:
Inference:
Contributor:
DiscoveredWBEMAssociatorsResult

Discovered WBEM Associators Results contributing to this Virtual Machine's attributes

Contributor Discovered WBEM Instances

InferredElement:
Inference:
Contributor:
DiscoveredWBEMInstance

Discovered WBEM Instances contributing to this Virtual Machine's attributes

Contributor Discovered WBEM Query Results

InferredElement:
Inference:
Contributor:
DiscoveredWBEMQueryResult

Discovered WBEM Query Results contributing to this Virtual Machine's attributes

Contributor Discovered WMI Query Results

InferredElement:
Inference:
Contributor:
DiscoveredWMI

Discovered WMI Query Results contributing to this Virtual Machine's attributes

Contributor Hosts

InferredElement:
Inference:
Contributor:
Host

Hosts contributing to this Virtual Machine's attributes

Contributor MF Parts

InferredElement:
Inference:
Contributor:
MFPart

MF Parts contributing to this Virtual Machine's attributes

Contributor Packages

InferredElement:
Inference:
Contributor:
Package

Packages contributing to this Virtual Machine's attributes

Contributor Patterns

InferredElement:
Inference:
Contributor:
Pattern

Patterns contributing to this Virtual Machine's attributes

Contributor Software Components

InferredElement:
Inference:
Contributor:
SoftwareComponent

Software Components contributing to this Virtual Machine's attributes

Contributor Software Containers

InferredElement:
Inference:
Contributor:
SoftwareContainer

Software Containers contributing to this Virtual Machine's attributes

Contributor Software Instances

InferredElement:
Inference:
Contributor:
SoftwareInstance

Software Instances contributing to this Virtual Machine's attributes

Primary Business Application

InferredElement:
Inference:
Primary:
BusinessApplicationInstance

Business Application from which the existence of this Virtual Machine was inferred

Primary Business Service

InferredElement:
Inference:
Primary:
BusinessService

Business Service from which the existence of this Virtual Machine was inferred

Primary Technical Service

InferredElement:
Inference:
Primary:
TechnicalService

Technical Service from which the existence of this Virtual Machine was inferred

Primary Device Info

InferredElement:
Inference:
Primary:
DeviceInfo

Device Info from which the existence of this Virtual Machine was inferred

Primary Discovered Application Component

InferredElement:
Inference:
Primary:
DiscoveredApplicationComponent

Discovered Application Component from which the existence of this Virtual Machine was inferred

Primary Discovered Cloud API Result List

InferredElement:
Inference:
Primary:
DiscoveredCloudAPIResultList

Discovered Cloud API Result List from which the existence of this Virtual Machine was inferred

Primary Discovered Coupling Facility

InferredElement:
Inference:
Primary:
DiscoveredCouplingFacility

Discovered Coupling Facility from which the existence of this Virtual Machine was inferred

Primary Discovered Database

InferredElement:
Inference:
Primary:
DiscoveredDatabase

Discovered Database from which the existence of this Virtual Machine was inferred

Primary Discovered Database Detail

InferredElement:
Inference:
Primary:
DiscoveredDatabaseDetail

Discovered Database Detail from which the existence of this Virtual Machine was inferred

Primary Discovered Directory Entry

InferredElement:
Inference:
Primary:
DiscoveredDirectoryEntry

Discovered Directory Entry from which the existence of this Virtual Machine was inferred

Primary Discovered Disk Drive

InferredElement:
Inference:
Primary:
DiscoveredDiskDrive

Discovered Disk Drive from which the existence of this Virtual Machine was inferred

Primary Discovered File

InferredElement:
Inference:
Primary:
DiscoveredFile

Discovered File from which the existence of this Virtual Machine was inferred

Primary Discovered File System

InferredElement:
Inference:
Primary:
DiscoveredFileSystem

Discovered File System from which the existence of this Virtual Machine was inferred

Primary Discovered HBA

InferredElement:
Inference:
Primary:
DiscoveredHBA

Discovered HBA from which the existence of this Virtual Machine was inferred

Primary Discovered IP Address

InferredElement:
Inference:
Primary:
DiscoveredIPAddress

Discovered IP Address from which the existence of this Virtual Machine was inferred

Primary Listening Port

InferredElement:
Inference:
Primary:
DiscoveredListeningPort

Listening Port from which the existence of this Virtual Machine was inferred

Primary Discovered MFPart

InferredElement:
Inference:
Primary:
DiscoveredMFPart

Discovered MFPart from which the existence of this Virtual Machine was inferred

Primary Discovered MQ Detail

InferredElement:
Inference:
Primary:
DiscoveredMQDetail

Discovered MQ Detail from which the existence of this Virtual Machine was inferred

Primary Discovered Mainframe

InferredElement:
Inference:
Primary:
DiscoveredMainframe

Discovered Mainframe from which the existence of this Virtual Machine was inferred

Primary Discovered Mainframe View Result

InferredElement:
Inference:
Primary:
DiscoveredMainframeViewResult

Discovered Mainframe View Result from which the existence of this Virtual Machine was inferred

Primary Discovered Network Interface

InferredElement:
Inference:
Primary:
DiscoveredNetworkInterface

Discovered Network Interface from which the existence of this Virtual Machine was inferred

Primary Discovered Process

InferredElement:
Inference:
Primary:
DiscoveredProcess

Discovered Process from which the existence of this Virtual Machine was inferred

Primary Discovered Program

InferredElement:
Inference:
Primary:
DiscoveredProgram

Discovered Program from which the existence of this Virtual Machine was inferred

Primary Discovered Registry Entry

InferredElement:
Inference:
Primary:
DiscoveredRegistryEntry

Discovered Registry Entry from which the existence of this Virtual Machine was inferred

Primary Discovered Service

InferredElement:
Inference:
Primary:
DiscoveredService

Discovered Service from which the existence of this Virtual Machine was inferred

Primary Discovered Software

InferredElement:
Inference:
Primary:
DiscoveredSoftware

Discovered Software from which the existence of this Virtual Machine was inferred

Primary Discovered Storage Subsystem

InferredElement:
Inference:
Primary:
DiscoveredStorageSubsystem

Discovered Storage Subsystem from which the existence of this Virtual Machine was inferred

Primary Discovered Sysplex

InferredElement:
Inference:
Primary:
DiscoveredSysplex

Discovered Sysplex from which the existence of this Virtual Machine was inferred

Primary Discovered Tape Drive

InferredElement:
Inference:
Primary:
DiscoveredTapeDrive

Discovered Tape Drive from which the existence of this Virtual Machine was inferred

Primary Discovered Transaction

InferredElement:
Inference:
Primary:
DiscoveredTransaction

Discovered Transaction from which the existence of this Virtual Machine was inferred

Primary Discovered Virtual Machine

InferredElement:
Inference:
Primary:
DiscoveredVirtualMachine

Discovered Virtual Machine from which the existence of this Virtual Machine was inferred

Primary Host Info

InferredElement:
Inference:
Primary:
HostInfo

Host Info from which the existence of this Virtual Machine was inferred

Primary MF Part

InferredElement:
Inference:
Primary:
MFPart

MF Part from which the existence of this Virtual Machine was inferred

Primary Network Connection List

InferredElement:
Inference:
Primary:
NetworkConnectionList

Network Connection List from which the existence of this Virtual Machine was inferred

Primary Software Component

InferredElement:
Inference:
Primary:
SoftwareComponent

Software Component from which the existence of this Virtual Machine was inferred

Primary Software Container

InferredElement:
Inference:
Primary:
SoftwareContainer

Software Container from which the existence of this Virtual Machine was inferred

Primary Software Instance

InferredElement:
Inference:
Primary:
SoftwareInstance

Software Instance from which the existence of this Virtual Machine was inferred

Maintaining Pattern

Element:
Maintainer:
Pattern:
Pattern

Pattern maintaining this Virtual Machine

Managed by Software Cluster

ManagedElement:
Management:
Manager:
SoftwareCluster

Software Cluster that manages this Virtual Machine

Managed by Software Instance

ManagedElement:
Management:
Manager:
SoftwareInstance

Software Instance that manages this Virtual Machine

Organizational Unit

OwnedItem:
Ownership:
Owner:
OrganisationalUnit

Organizational Unit that this Virtual Machine belongs to

Containing Business Application

ContainedSoftware:
SoftwareContainment:
SoftwareContainer:
BusinessApplicationInstance

Containing Business Application

Containing Business Service

ContainedSoftware:
SoftwareContainment:
SoftwareContainer:
BusinessService

Containing Business Service

Containing Technical Service

ContainedSoftware:
SoftwareContainment:
SoftwareContainer:
TechnicalService

Containing Technical Service

Cluster Member

ServiceHost:
SoftwareService:
Service:
ClusterMember

Cluster Member that represents this Virtual Machine

Load Balancer Member

ServiceHost:
SoftwareService:
Service:
LoadBalancerMember

Load Balancer Member that represents this Virtual Machine

Disk Drives Used

Consumer:
StorageUse:
Provider:
DiskDrive

Disk Drives used by this Virtual Machine

Software Support Details

ElementWithDetail:
SupportDetail:
SoftwareDetail:
SupportDetail

Software Support Details for this Virtual Machine
